High-concentration ozone generators for water treatment, disinfection, and industrial applications. Scalable from 20 to 500 g/hr. Engineered and manufactured in India.
Up to 20 wt% ozone concentration — highest available from a compact ceramic DBD reactor. More ozone per unit of oxygen and energy consumed.
Oxygen consumption varies linearly with ozone output — unlike conventional systems that run at constant flow. Half the energy, half the running cost.
Start with a 20 g/hr standard unit. Add electrode cells to reach 100 g/hr with the same PCB. Upgrade to 500 g/hr with enhanced electronics. No over-buying.
Robust all-aluminium ceramic DBD cell design. High gas pressure prevents contamination. Zero scheduled cleaning. Maximum uptime with minimal maintenance.
Power electronics and DBD cells cooled internally. No external air-conditioning or chiller required. Smaller footprint, lower infrastructure cost.
Designed and manufactured in Chennai by VIOMAX Enviro Solutions. Local support, fast delivery, and competitive pricing for Indian and export markets.
Ceramic DBD Cell Array — Active Discharge
Live Performance Metrics
VIOMAX ozone generators use Ceramic Dielectric Barrier Discharge — a cold plasma process that converts oxygen into high-concentration ozone with minimal energy loss.
Three capacity tiers. One common design philosophy. Scalable without reinventing the system.
From compact medical units to large municipal installations — ozone technology that scales with your needs.
COD reduction, colour removal, micro-pollutant elimination and disinfection for municipal and industrial effluent. CPCB-compliant solutions.
Precise medical-grade ozone output for ozone therapy clinics. Pairs with standard oxygen concentrator for a complete, compact clinical solution.
Reduce chlorine use, eliminate chloramines, and achieve crystal-clear water with ozone as primary disinfection. Plug-and-play for pools of any size.
Chemical-free wash water treatment, surface sanitation, and CIP cycle enhancement. Zero residue — ozone decomposes to oxygen. CE-mark aligned.
Ozone treatment for recirculating aquaculture systems — removes nitrite, TAN, and pathogens. Proven to increase fish growth rates and reduce mortality.
Cooling tower water treatment, textile effluent colour removal, odour control, and pharmaceutical water purification for GMP-compliant environments.
Compare VIOMAX ceramic DBD technology against conventional glass-tube ozone systems.
| Feature | VIOMAX | Conventional |
|---|---|---|
| Ozone Concentration | Up to 20 wt% | 8–14 wt% |
| Cell Maintenance | Not Required | Periodic Cleaning |
| O₂ Consumption | Linear (Proportional) | Constant Flow |
| Output Pressure | 3× Higher | Low Pressure |
| Booster Pumps | Not Required | Required |
| Air Conditioning | Not Required | Required |
| Cell Replacement | Not Required | Periodic |
| Modular Scaling | ✔ Cell Stacking | Full Replacement |
Tell us about your application — flow rate, ozone dose required, water quality parameters, and environment. We'll help you size the right system.
Our application engineers review your requirements and issue a technical proposal with model selection, schematic, and commercial quotation within 2–3 working days.
On order confirmation, manufacturing begins. Every unit undergoes a Factory Acceptance Test before despatch. Lead time: 3–12 weeks depending on model.
Site delivery, installation guidance, operator training, and 12-month warranty. Ongoing technical support and spare parts available from our Chennai facility.
Tell us about your ozone application and we'll design the right system for you. No obligation — just expert advice.
Three capacity tiers built on a common ceramic DBD platform. Scale from 20 g/hr to 500 g/hr as your needs grow — without changing the core technology.
The proven foundation of the VIOMAX range. Designed around a single ceramic DBD cell, the VM-20 delivers reliable, cost-effective ozone generation out of the box. Ideal for general wastewater treatment, medical ozone therapy, pool disinfection, and food sanitation.
| Parameter | VM-20 | VM-50 | VM-100 | VM-200 | VM-500 |
|---|---|---|---|---|---|
| DBD Cell Modules | 1 | 2–3 | 4–5 | 10–12 | 22–25 |
| Ozone Output | 20 g/hr | 50 g/hr | 100 g/hr | 200 g/hr | 500 g/hr |
| Max Concentration | Up to 20 wt% — all models | ||||
| Output Pressure | Up to 3.0 barg (standard) | ||||
| Power Supply | 230V / 50Hz, Single-Phase | 230V or 415V 3-phase | |||
| PCB / Electronics | Standard (same board) | Upgraded multi-stage | |||
| Control Interface | Rotary + Digital Meter | HMI + 4-20mA | PLC / SCADA / Modbus | ||
| O₂ Consumption (g/hr) | ~70 | ~175 | ~350 | ~700 | ~1750 |
| Power Consumption | ~150W | ~350W | ~650W | ~1.2kW | ~3kW |
How VIOMAX converts oxygen into high-concentration ozone with less energy, no fragile glass components, and no scheduled maintenance.
Ozone (O₃) is produced by passing oxygen (O₂) through a high-frequency electrical discharge field — known as Dielectric Barrier Discharge (DBD) or cold plasma.
In VIOMAX generators, ceramic plates act as the dielectric barrier between two electrodes. When high-voltage, high-frequency AC is applied, a corona discharge forms in the gap — dissociating O₂ molecules into oxygen radicals, which then recombine into O₃.
The square-geometry cell design in VIOMAX units creates a uniform discharge field across the full electrode surface — unlike cylindrical glass tubes where the field is concentrated and uneven. This uniformity means more ozone per watt of electricity and per cubic metre of oxygen consumed.
Ceramic DBD Cell — Cross Section
VIOMAX produces ozone up to 20 wt% — compared to 8–14 wt% from conventional glass-tube systems. Higher concentration means better water dissolution and less oxygen wasted.
Ceramic dielectric does not crack, degrade, or require periodic replacement — unlike glass tubes. VIOMAX cells are designed for years of continuous operation with no cell maintenance.
The core PCB and electronics are engineered to drive up to 5 cells — scaling from 20 g/hr to 100 g/hr simply by adding ceramic DBD cell modules. No redesign. No new board.
VIOMAX ozone generators serve industries where clean water, safe food, and hygienic environments are non-negotiable.
Ozone is one of the most powerful oxidisers available for wastewater treatment. VIOMAX systems are used for BOD/COD reduction, colour removal from textile effluent, pharmaceutical wastewater, and CPCB/SPCB-compliant discharge treatment.
The VM-20 is the preferred choice for ozone therapy clinics, hospitals, and wellness centres. Precision output control, medical-grade oxygen inlet, and quiet operation make it ideal for clinical environments.
Ozone water treatment in recirculating aquaculture systems (RAS) has been proven to increase fish growth rates, reduce mortality, and improve water quality — reducing the frequency of water exchanges and lowering operating costs.
Advanced ozone generation technology, engineered and manufactured in India — for India and the world.
VIOMAX Enviro Solutions Pvt. Ltd. was founded with a singular mission: to make advanced ozone generation technology accessible, affordable, and practical for Indian industry.
Our team of engineers developed the VIOMAX VM Series around Ceramic Dielectric Barrier Discharge technology — a significant step beyond the conventional glass-tube generators that dominate the market. The result is a system that produces higher ozone concentrations, consumes less energy and oxygen, and requires virtually no maintenance.
Every VIOMAX generator is designed, assembled, and tested at our facility in Chennai, Tamil Nadu. We serve customers across India and export to neighbouring markets, with applications spanning water treatment, healthcare, food processing, aquaculture, and industrial disinfection.
We believe India deserves world-class ozone technology, designed and built locally. Every VIOMAX unit is a step toward cleaner water and healthier environments.
Request a quotation, ask a technical question, or just tell us about your application. Our engineers are ready to help.
We respond to all enquiries within 1–2 working days. For urgent queries, email us directly.
For product datasheets, model selection guidance, or application-specific advice, email us directly at info@viomax.in with details of your application.
By submitting, you agree that VIOMAX may contact you about your enquiry. We do not share your details with third parties.
